RFLoXa
RFloXa Hawk31 PRO Front Fork
Direct fit for the Ventus One. The RFloXa Hawk31 Pro fork does provide some improvement over the stock Fastace forks.
About this item
① High-Performance Design -- The Hawk31 PRO front fork features an impressive travel range of 203-228mm (if need up to another length, need contact us to customize) and is designed for top-tier performance in downhill and off-road biking. With a stanchion diameter of 37mm and a caliper mount spacing of 74mm, it’s compatible with 203mm disc brakes (with options for upgrades), making it ideal for electric dirt bikes and downhill bikes.
② Advanced Suspension Technology -- This fork employs an inverted oil-spring damping system with asymmetrical left and right legs for a unique, independent structure. It includes multi-stage adjustments for high-speed compression damping, low-speed compression damping, rebound damping, and spring preload, allowing for precise tuning to match your riding style and terrain.
③ Robust Build Quality -- Constructed with AL6061-T6 forged aluminum alloy for the bottom brackets and AL7075-T6 aluminum alloy for the fork tubes, the Hawk31 PRO is built for durability and strength. The use of 55CRSI spring wire ensures resilience and performance under stress.
④ Customizable Adjustments -- All adjustment functions, including compression, rebound, and preload settings, are controlled by easy-to-use manual knobs. This allows for quick and convenient tuning in various riding conditions, ensuring optimal performance and comfort.
⑤ Enhanced Bottom-Out Support -- The fork features a unique oil pressure bottom-out design that provides strong support at the end of the travel, enhancing stability and reducing the impact of hard hits.
⑥ Reliable Damping Performance -- The internal damping system includes dual compression valve plates, ensuring stable and reliable compression damping. The fork uses high-quality, low-friction, low-freezing-point shock absorber oil to maintain consistent damping performance, even in extreme conditions.
FEATURES:
- Center Distance: 750-800mm
- Main Piston Travel: 203-228mm
- Tube Diameter: ∅37mm
- Caliper Mount Spacing: 74mm
- Disc Brake Size: ∅203mm (Upgradeable)
- Suitable For: Electric Dirt Bikes, Downhill Bikes
- Damping System: Inverted Oil-Spring
- Adjustments: Multi-stage High-Speed Compression, Low-Speed Compression, Rebound, Spring Preload
- Material: AL6061-T6 Forged Aluminum Alloy Bottom Brackets, AL7075-T6 Aluminum Fork Tubes
- Spring Wire: 55CRSI
- Triple Clamp: CNC Precision Machined
See all specifications
Weight for 203mm travel fork:(compatible with 19 inches)
- 45lbs spring - ≤100kg
- 60lbs spring - 100kg-130kg
- 45-60lbs progressive spring - 80kg-130kg
Weight for 228mm travel fork: (compatible with 19/21 inches)
- 45lbs spring - ≤100kg
- 55lbs spring - 100kg-130kg
RFloXa Features
Low-Speed Compression Damping (LSC)
Reduces bounce and instability during low-speed movements like pedaling and climbing, improving ride stability and comfort.
High-Speed Compression Damping (HSC)
Prevents the shock from bottoming out on rapid impacts, maintaining control and stability during intense hits.
Rebound & Spring Preload Adjustments
Tuning rebound damping for smoothness or stability based on weight and terrain. Adjust spring preload to match rider weight and improve support.
